Asus PRIME B760M-K, Intel B760, 1700, Micro ATX, 2 DDR5, VGA, HDMI, 2.5G LAN, PCIe4, 2x M.2

Motherboard TypeDesktopForm FactorMicro ATXSocketIntel 1700ChipsetIntel B760CPU SupportClick here for CPU supportRAM TechnologyDDR5 (Dual Channel)
Non-ECC, Un-buffered Memory
Non-ECC, un-buffered DDR5 memory supports On-Die ECC function
Supports Intel Extreme Memory Profile (XMP)RAM Slots2 x DIMMRAM SpeedsUp to 8000(OC)Maximum Memory96GBGraphicsIntegrated Graphics*
*Graphics specifications may vary between CPU typesGraphics Ports1 x VGA
1 x HDMIPCI/PCI Express1 x PCIe 4.0 x16
2 x PCIe 4.0 x1Storage4 x SATA III
1 x M.2 (2242/2260/2280) - PCIe 4.0 x4
1 x M.2 (2242/2260/2280) - PCIe 4.0 x4RAIDIntel Rapid Storage Technology supports SATA RAID 0/1/5/10Wireless-LAN2.5GB LANAudioRealtek 7.1 Surround Sound High Definition Audio CODEC*USB Ports SupportedRear:
4 x USB 3.2 Gen1 Type-A
2 x USB 2.0

Front:
2 x USB 3.2 Gen1
3 x USB 2.0Back Panel I/O Ports4 x USB 3.2 Gen1 Type-A
2 x USB 2.0
1 x VGA
1 x HDMI
1 x Realtek 2.5Gb Ethernet
3 x Audio jacks
1 x PS/2 Keyboard/Mouse comboInternal I/O Connectors1 x 4-pin CPU Fan
2 x 4-pin Chassis Fan
1 x 24-pin Main
1 x 8-pin +12V
2 x M.2 (Key M)
4 x SATA 6Gb/s
1 x USB 3.2 Gen1
2 x USB 2.0
2 x Addressable Gen2
1 x Aura RGB
1 x Clear CMOS
1 x COM Port 1 x Front Panel Audio
1 x S/PDIF Out
1 x Speaker
1 x SPI TPM (14-1pin)
1 x 10-1 pin System PanelAccessories2 x SATA 6Gb/s cables
1 x I/O Shield
2 x M.2 anchors
1 x User guideAdditional FeaturesSee OverviewPackage TypeRetailPackage WeightTo be confirmedWarranty3 Years


ASUS Prime B760M-K, an Intel® B760 LGA 1700 mATX motherboard with PCIe 4.0, two PCIe 4.0 M.2 slots, DDR5, Realtek 2.5Gb Ethernet, VGA, HDMI™, SATA 6 Gbps, front USB 3.2 Gen 1, Aura Sync

Intel® LGA 1700 Socket: Ready for 13th and 12th Gen Intel® processors
Ultrafast Connectivity: PCIe 4.0, two PCIe 4.0 M.2 slots, Realtek 2.5Gb Ethernet and front USB 3.2 Gen 1 support
Comprehensive Cooling: VRM heatsink, PCH heatsink, hybrid fan headers and Fan Xpert 2+
Aura Sync RGB Lighting: Onboard Addressable Gen 2 headers and Aura RGB header for RGB LED strips, easily synced with Aura Sync-capable hardware





Prime

ASUS Prime series motherboards are expertly engineered to unleash the full potential of 13th Gen Intel® Core™ Processors. Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, PRIME B760M-K provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features.




Flexibility

Comprehensive controls form the foundation of the ASUS PRIME series. The PRIME B760 motherboard packs flexible tools to tune every aspect of your system, enabling performance tweaks to perfectly match the way you work to maximize productivity.




Cooling

PRIME B760 series are engineered with multiple onboard heatsinks and an array of hybrid fan headers to ensure your rig stays cool and stable under intense workloads.




Performance

The PRIME B760 series are built to handle the high core counts and bandwidth demands of 13th Gen Intel® Core™ Processors. ASUS B760 motherboard provides all the fundamentals to boost daily productivity, so your system will be ready for action with stable power, intuitive cooling and flexible data transfer options.




Customization

PRIME B760 series add the nuanced details that improve every experience, from exclusive codecs that provide pristine audio quality to intuitive RGB lighting controls that let you customize your system to create a uniquely personal look.
